The Auto Loader is a type of auxiliary machinery that automatically conveys the material from storage containers to the hopper of the injection moulding machine. Auto loaders are constructed from lightweight stainless steel hoppers, ensuring that the material being conveyed is free from contamination and/or clean. Additionally, as an Auto Loader has motor overload protection, material shortage alarms, and a microprocessor-controlled automatic shutoff, they are safe, reliable, and can be operated unattended. Auto loaders are used for conveying many different types of plastic granules and powders, and improve overall workflow efficiency and reduce manual handling.
Auto Loader
Lightweight stainless steel material hopper
Automatic motor overload protection
Equipped with material lacking alarm
Micro processor control
For conveying wide variety of granules and powder
| Model | STL-300GN | STL-600GN | STL-800GN | STL-900GN-2 | STL-800GN2-P | ||
| Motor | Type | Carbon bush | Induction | Induction | Induction | Induction | |
| Specification | 1100w1Ø | 1500w3Ø | 2200w3Ø | 2200w3Ø | 1100w3Ø | ||
| Conveying capacity | kg/hr | 400 | 450 | 550 | 450+450 | 650 | |
| Static wind pressure | Max | 1500mmAq | 1450mmAq | 2000mmAq | 2000mmAq | 1450mmAq | |
| Filter | mm | Ø185*110H | Ø185*110H | Ø185*110H | Ø185*110H | Ø185*110H | |
| Volume of material hopper | L | 6 | 6.5 | 6.5 | 6.5+12 | 18 | |
| Inside diameter of conveying pipe | mm | Ø38 | Ø38 | Ø38 | Ø38 | Ø38 | |
| External size | Main body L×W×H | mm | 480*310*430 | 680*370*500 | 700*370*500 | 850*480*740 | 680*370*500 |
| Material hopper L×W×H | mm | 430*440*295 | 430*440*295 | 430*440*295 | 430*440*500 | 430*440*700 | |
| Weight | Main body | kg | 20 | 55 | 65 | 70 | 60 |
| Material hopper | kg | 6 | 6 | 6 | 6+6 | 12 | |
